XHP-8
JST
Designed for multi-circuit power and signal transmission, this shrouded header crimp-style connector features a 2.5mm pitch, 8-pin configuration, and a compact 9.8mm mounting height, making it the go-to choice for business customers in industrial, automotive, and home appliance industries requiring robust, high-current PCB board-mount interconnects. Our XHP-8 wire to board crimp connectors deliver exceptional electrical performance and mating security, reducing assembly errors and enhancing end-product durability for your business.
Parameter | Specification Details |
Series Title | XH CONNECTOR |
Brand | JST |
Model Number | XHP-8 |
Connector Type | Wire-to-Board Crimp Style, Shrouded Header Disconnectable Type |
Pitch | 2.5mm |
Pin Count | 8 Pin |
Rated Current | 3A (AWG#22) |
Rated Voltage | 250V AC/DC |
Mounting Height | 9.8mm |
Installation Direction | Top Entry / Side Entry |
Mounting Type | PCB Board-Mount |
Termination Style | Crimp Contact |
With a 3A rated current per circuit and 250V rated voltage, our 2.5mm pitch JST XH PCB connectors support both power and signal transmission in a single compact housing, eliminating the need for separate power and signal connectors and simplifying your PCB design. This makes it ideal for medium-power electronic applications requiring stable multi-circuit connections.
The integrated shrouded header structure prevents reverse mating and mis-insertion during assembly, significantly reducing production line defect rates and rework costs. The robust locking mechanism ensures secure retention even in high-vibration industrial and automotive environments, eliminating the risk of accidental disconnection and improving long-term operational reliability.
With a minimal 9.8mm mounting height, our 8Pin JST XH board-mount connectors optimize vertical space on your PCB, making it suitable for low-profile device designs without compromising on electrical performance. The dual top and side entry installation options offer maximum flexibility for 3D mechanical design and PCB layout planning.
We provide end-to-end OEM/ODM customization solutions tailored to your project requirements for JST XH 2.5mm 8Pin Crimp Board-Mount Connectors. Our customization capabilities include custom terminal plating (high-temperature tin plating, gold plating for harsh environments), custom pin length and configuration, custom housing color and material for high-temperature applications, pre-crimped wire harness assemblies with overmolding, and custom PCB mounting footprint adaptation. Our professional engineering team offers design optimization support to ensure the connector perfectly matches your product’s mechanical and electrical requirements, from prototype validation to full-scale mass production.
Our XHP-8 JST XH 2.5mm 8Pin connectors are widely adopted across diverse business sectors, including automotive power & control systems for in-vehicle power distribution modules, automotive body control units, and automotive harness assemblies, industrial automation & power supplies for industrial PLC systems, switching power supplies, servo drive control circuits, large home appliances & white goods for washing machines, refrigerators, air conditioner control boards, and high-power household appliance wiring, and telecommunications & power distribution for network equipment, power distribution units, and backup power system interconnects.
All our JST XH series board-mount connectors are manufactured in strict compliance with JST original quality standards, with full batch traceability. We implement rigorous multi-stage quality control, including insulation resistance testing, voltage withstand testing, mechanical life cycle testing, and high-low temperature cycle testing, to ensure every product meets industrial and automotive-grade reliability requirements. Our products hold UL certification, and fully comply with RoHS and REACH global environmental regulations, supporting seamless market access worldwide.
Standard packaging uses original JST anti-static tube and reel packaging, fully compatible with automated assembly processes. We also offer custom packaging including moisture-proof anti-static bags, tray packaging, or customer-specified packaging for automated production lines. For delivery, in-stock bulk orders are shipped within 72 hours; custom order lead times are confirmed based on your customization requirements. We support a full range of international trade terms (EXW, FOB, CIF, DDP) and global door-to-door logistics services to streamline your supply chain management.
Our XHP-8 connectors are UL certified, and fully comply with RoHS and REACH international environmental standards, meeting the regulatory requirements of major global markets including North America, Europe, and Asia.
Yes, the XH series is widely used in automotive body control and power distribution systems, with excellent vibration resistance and stable performance that meets the strict requirements of automotive electronic applications.
Yes, we provide full custom overmolding and wire harness assembly services, including strain relief and environmental sealing, to deliver fully tested, ready-to-install interconnect solutions for your production line.
