1717088 - PHOENIX

Type: PC terminal block can be aligned

Product type: Printed circuit board terminal

Product family: MKDSFW 1,5

Number of positions: 3

Pitch: 5 mm

Pin layout: Linear pinning

Contact material: Cu  alloy

Metal surface terminal point (top layer): Tin (5 - 7 µm Sn)

Metal surface soldering area (top layer): Tin (5 - 7 µm Sn)

Color (Housing): green (6021)

Insulating material: PA

Insulating material group: I

CTI according to IEC 60112: 600

Flammability rating according to UL 94: V2

Packing unit: 50 pc

Minimum order quantity: 50 pc

Product key: AALFGN

Catalog page: Page 97 (C-1-2013)

GTIN: 4017918024277

Weight per piece (including packing): 4.73 g

Weight per piece (excluding packing): 4.4 g

Customs tariff number: 85369010

Country of origin: PL
